RL01K1-C0 Short-Wave Infrared Linear Array Detector
- Model:
- RL01K1-C0
Features
Pixel Pitch
12.5μm
Area Array Size
1024×1
Operating Power Consumption
≤200mW
Outline Dimensions
28.91×18.64×4.0mm3 (excluding pin size)
Device Weight
8±2g
Description
The short-wave infrared linear array is based on advanced InGaAs sensor technology, with an array size of 1024×1, a pixel pitch of 12.5μm, and a spectral response of 0.9-1.7μm. This linear array detector uses a TECless ceramic package and features high resolution, high line rate, low noise, and SWaP (Size, Weight, and Power) characteristics.
It can be widely used in applications such as agricultural product sorting, resource recycling, industrial sorting, photovoltaic inspection, and machine vision.
Specifications
Technical Specifications
RL01K1-C0
Sensor
InGaAs
Spectral Response Range
0.9μm – 1.7μm
Quantum Efficiency
>70% (1.0μm – 1.6μm)
Optical Fill Factor
100%
Pixel Pitch
12.5μm
Area Array Size
1024×1
Effective Pixel Rate
> 99.8%
Maximum Output Line Frequency
36kHz
Readout Mode
ITR, IWR
Minimum Integration Time
15μs
Readout Noise (Typical)
≤50e@1-36kHz, 20°C
Optional Gain
≥4-level
Average Pixel Dark Current
≤100ke/s@20℃
Operating Power Consumption
≤200mW
Output Signal Swing
1.9±0.1V
Dynamic Range
≥58dB
Response Non-uniformity
≤5%, non-corrected
Packaging Type
PGA ceramic packaging (TECless)
Outline Dimensions
28.91×18.64×4.0mm3 (excluding pin size)
Device Weight
8±2g
Operating Case Temperature
-20°C – +50°C
Storage Case Temperature
-40°C – +60°C
